compresores de aire móviles
buying a gas compressor?
compresores de aire de gasolina,
servicio de compresor de aire
GAS COMPRESSORS FOR: tow trucks; mobile truck services; tire replacement; emergency tire replacement services; road service; truck repair; 18 wheeler repair; roadside assistance; tire repair; etc.
Most compressors that you purchase at your local BIG BOX retailors are JUNK...They will not last and they are not designed for heavy duty industrial jobs.
The best gas compressors on the market are:
#1 Curtis 13HP CA Series
#2 Ingersoll Rand
#3 Jenny air compressors
#4 Quincy gas compressor
#5 Champion gas compressor
FS-Curtis CT13-H 13 HP Gas Honda 30 Gallon Horizontal Air Compressor
FCTHEC75H3X-AXL1XX |
CA13 - H & CA14 - K GAS ENGINE | ||
| TECHNICAL DATA | |||
| Capacity and power: ISO-1217(1996 annex #C) | |||
| Normal working pressure - psi | 175 | ||
| Motor | Honda | Kohler | |
| Capacity at normal working press - cfm | 22.0 | 22.5 | |
| Basic Pump | |||
| Model | E57 | ||
| Stage | 2 | ||
| Lubrication type | Splash Lubrication | ||
| Valve type | Channel Valve - Stainless Steel | ||
| RPM (min - max) - rpm | 500 - 1250 | ||
| Outfit RPM | 927 | ||
| BHP - HP | 15.73 | ||
| Bore (LP/HP) - inch | (2) 4.72” - 3.93” | ||
| Stroke - inch | 3.15” | ||
| Inlet size | Rc1 BSPT | ||
| Discharge size | 1 1/8”OD | ||
| Sheave OD | 13.86” | ||
| Sheave PD | 13.51” | ||
| Number of belts | 2 | ||
| Belt section | A - Banded | ||
| Low oil sight glass | Sight Glass | ||
| Oil quantity | 5 Pints | ||
| Unloaders and Method | Load Genie Check Valve | ||
| Motor | Honda | Kohler | |
| Ambient Air Temp - Max/Min °F | 32-104 | 32-104 | |
| Oil Capacity - Gal | 1.16 Quarts | 1.37 Quarts | |
| Nominal rated net power - HP | 11.7 | 12.1 | |
| Speed of rotation - rpm | 3600 | 3600 | |
| Noise level - dB(A) | 104 | 105.4 | |
| Installation condition | |||
| Allowed ambient temperature min - max - °F | 32-104 | ||
| Compressor dimensions | CA13-H | CA14-K | |
| Air Receiver Type | Horizontal | Horizontal | |
| Air receiver size (Gal) | 30 | 30 | |
| Compressor outlet | 1/2” NPT | 1/2” NPT | |
| Length - inch | 50 | 50 | |
| Width - inch | 24 | 24 | |
| Height - inch | 50 | 43 | |
| Weight - Lbs. | 460 | 486 | |
| Air Cooled Aftercooler (Option) | |||
| Availability | N/A | ||
| Air cooled aftercooler CTD - °F | N/A |
Some of the worst portable gas powered air
compressors:
·
If
you buy your compressor from one of the large box stores and your compressor
breaks down…Don’t expect them to fix it or provide you with any parts. Since many of the parts are made in China,
you may have a difficult time tracking down the parts.
·
NO
SERVICE……NO PARTS….Where do you go for service or warranty work?
ALL CAST IRON MACHINES.
si necesita comprar un compresor de aire nuevo o si su
antiguo compresor tiene problemas; llámanos al: 214-428-2868
CURTIS 13HP GAS COMPRESSOR.
Gas-driven
models are ideal for applications that require air when electricity isn’t
readily available. FS-Curtis gas-driven models are perfect for fleet and
service applications.
•
Choose between Kohler or Honda engines
•
Tank mount or base mount configurations
•
OSHA-approved totally enclosed metal belt guard
•
ASME-approved air receiver
•
12V DC starter with alternator
•
Engine idle control
compresores de aire para
la industria automotriz. máquinas; llantas; colisión y reparación; pintura;
mecanizado cnc; impresión; reparación de autos; herramientas de aire;
reparación de camiones grandes; plantas de reciclaje, instalaciones de
procesamiento de alimentos; instalaciones de cemento;
GAS COMPRESSOR
WWW.HKAIRCOMPRESSORS.COM
H&K PUMP
214-428-2868
GAS COMPRESSOR
CURTIS 13HP GAS AIR COMPRESSOR
GAS AIR COMPRESSOR
214-428-2868
214-428-2868
Llevamos más de 50 años en el negocio de los compresores de aire. Si no
podemos reparar su compresor de aire, entonces USTED tiene un problema. Podemos
reparar casi todos los compresores fabricados en Estados Unidos.
BEST GAS AIR COMPRESSORS
WWW.HKAIRCOMPRESSORS.COM
WWW.HKAIRCOMPRESSORS.COM
compresores de aire móviles
WWW.HKAIRCOMPRESSORS.COM
H&K PUMP
214-428-2868
WWW.HKAIRCOMPRESSORS.COM
H&K PUMP
214-428-2868
WWW.HKAIRCOMPRESSORS.COM
H&K PUMP
214-428-2868
WWW.HKAIRCOMPRESSORS.COM
H&K PUMP
214-428-2868
WWW.HKAIRCOMPRESSORS.COM
H&K PUMP
214-428-2868
WWW.HKAIRCOMPRESSORS.COM
H&K PUMP
214-428-2868
compresores de aire para la industria automotriz. máquinas; llantas;
colisión y reparación; pintura; mecanizado cnc; impresión; reparación de autos;
herramientas de aire; reparación de camiones grandes; plantas de reciclaje,
instalaciones de procesamiento de alimentos; instalaciones de cemento;
compresores de aire para máquinas de neumáticos
WWW.HKAIRCOMPRESSORS.COM
H&K PUMP
214-428-2868
| FCAHEE57B1X-AXL1XX | CA13 HORZ 1G BASE MOUNT 175PSI STD |
| FCAHEE57H3X-AXL1XX | CA13 HORZ 30G 175PSI SPEC |
| FCAKDE57H3X-AXL1XX | CA14 HORZ 30G 175PSI SPEC |
entregamos e instalamos
compresores de aire en sus instalaciones. También reparamos compresores de aire
y bombas de compresores de aire. llámanos al: 214-428-2868
compresores de aire para máquinas de neumáticos
