| PART LIST FOR THE RSB40-50 | ||||
| ITEM | PART NUMBER | |||
| DESCRIPTION | Q | |||
| NO | RSB40 | RSB50 | ||
| 1 | BASE 42 X 72 DARK GREY RS40-50F, 50D | 1 | FRN10116-15 | < |
| 2 | TANK AIR/OIL SEPARATOR 14" DIA 19 GAL | 1 | FRN10222-2 | < |
| 3 | BSA31S(4v5/CURTIS/SingleSeal/RAL7026) | 1 | 2A05190279 | < |
| MOTOR, 3PHASE, 60HZ, 200V, ODP | FMT409X2 | FMT509X2 | ||
| 4 | MOTOR, 3PHASE, 60 HZ, 230/460V ODP | 1 | FMT403X2 | FMT503X2Y |
| MOTOR, 3PHASE, 60HZ, 575V, ODP | FMT408X2Y | FMT508X2 | ||
| MOTOR 1 1/2HP, 3 PHASE, 60HZ, 200V ODP | FMT119X4 | FMT029X4 | ||
| 5 | MOTOR 1 1/2HP, 3 PHASE, 60HZ, 230/460V ODP | 1 | FMT113X4 | FMT023X4 |
| MOTOR 1 1/2HP, 3 PHASE, 60HZ, 575V ODP | FMT118X4 | FMT028X4 | ||
| 6 | FAN SHROUD | 1 | FCS731 | FCS730 |
| 7 | COOLER SUPPORT-LEFT | 1 | FCS700 | < |
| 8 | COOLER AIR/OIL (R/S 40-50) | 1 | 2689510030 | < |
| 9 | FAN MOTOR MOUNT R/S 40-50 | 1 | FRN10120-8 | < |
| 10 | BRACKET, OIL FILTER | 1 | FCS717A | < |
| 11 | SUPPORT, ELECTRICAL ENCL. 39" | 2 | FCS677-2 | < |
| 12 | BELTGUARD, BACK BSA32 R/S40-50F | 1 | FRN10510-11 | < |
| 13 | GUARD BELT FRONT R/S 40-50 | 1 | FRN10510 | < |
| 14 | INLET VALVE DN65 110V | 1 | 2104050162 | < |
| 14A | O-RING | 1 | INCLUDED | < |
| 15 | MOTOR BASE ODP | 1 | FRN12030 | FRN12040 |
| 16 | GUARD FAN 24 " RD WIRE | 1 | FRN10456 | < |
| 17 | SEPARATOR, ELEMENT | 1 | FRN27518 | < |
| 18 | TUBE 1 1/2" O.D. | 1 | FOFE981 | < |
| 19 | MOUNT BASE BSA31S BOLTED RSB40-50 | 1 | FRN10176 | < |
| 20 | TUBE-BY-PASS TO OIL FILTER 3/4" OD. | 1 | FOFE959 | < |
| 21 | TUBE 1 1/4" O.D.X 0.049 | 1 | FOFE949 | < |
| 22 | TUBE-SEPARATOR TANK TO BY-PASS 3/4"OD | 1 | FOFE960 | < |
| CONTROL PANEL SIZE "K" | F1330000 | < | ||
| 23 | 1 | |||
| CONTROL PANEL SIZE "N" | F1330001 | < | ||
| 24 | PLUG PLASTIC, 2" SQ. TUBE | 2 | F1030004 | < |
| 26 | CONNECTOR 3/4BSPP X 3/4" 37FL | 1 | FVAC749 | < |
| 27 | SEAL BONDED W/VAA745 ADAP | 3 | FVAA746 | < |
| 28 | ADAPTER 1/8 BSPP MALE X 1/4 NPTF | 3 | FVAA745 | < |
| 29 | ELBOW, MALE 90 DEGREE 1/4" NPTM X 1/4" NPTM STEEL | 1 | FVAA754 | < |
| 30 | CHECK/SIGHT GLASS/2mm ORIFICE COMBO VALVE | 1 | 2605332920 | < |
| 31 | COMPRESSION CONNECTOR 1/4"NPTx 3/8”OD ELBOW | 2 | FRN52150-12 | < |
| 32 | THERMOWELL 1/4"BSPPx 7/16-24UNS 6MM PRO | 1 | FRN18694 | < |
| 33 | SEAL BONDED BSPP 1/4 | 1 | 2109120008 | < |
| 34 | NIPPLE 1 1/4 X 5 1/2 | 1 | FPTN0716AS | < |
| 35 | CONNECTOR, 1/4OD X 1/4NPT, MALE, ELBOW | 2 | FRN52150-2 | < |
| 36 | VALVE MIN PRESS 1 1/4" | 1 | FRN42126 | < |
| 36A | KIT REPAIR MIN. PRESSURE VALVE | 1 | FRN42126-1 | < |
| 37 | PRESSURE-AIR GAUGE, 300 PSI 2 1/2 " | 2 | FRN30323 | < |
| 38 | CONNECTOR 1 1/4"NPT X 1 1/4"OD ELBOW-MALE | 1 | FVAA722 | < |
| 40 | TEE REDUCING 1 X 3/4 X 3/4 | 1 | FVAE803 | < |
| 41 | NIPPLE 1 X 5 1/2" | 1 | FPTN0616AS | < |
| 42 | CONNECTOR 3/4"NPT X 3/4"OD.STRAIGHT | 1 | FVAA717 | < |
| 43 | FAN-ASSY 45 DEG PITCH | 1 | FRN32419 | FRN32406 |
| 44 | DRAIN COCK 1/4" | 1 | FVV514 | < |
| 45 | HHCS 5/16-18 X 1" GRADE 5 ZINC PLATED | 13 | FVH12HH1 | < |
| 46 | FLAT WASHER 5/16 ZINC PLATED | 11 | FVH32H1 | < |
| 47 | WASHER-CUT-FLAT 1/4" | 7 | FVH32F | < |
| 48 | LOCK WASHER ZINC PLATED 1/4" MEDIUM | 19 | FVH35F1 | < |
| 49 | HHCS 1/4-20 X 3/4" LONG ZINC PLATED | 21 | FVH12FF1 | < |
| 50 | LOCK WASHER 5/16 SPLIT ZINC PLATED | 13 | FVH35H1 | < |
| 51 | NUT HEX 5/16-18 ZINC PLATED | 7 | FVH15H1 | < |
| 52 | NUT-HEX 10-24 | 4 | F4440 | < |
| 53 | GUARD CLIPS | 4 | FRN10455-1 | < |
| 54 | SCREW-HEX HD. MACHINE 10-24 | 4 | FVH11DD | < |
| 55 | SPIN ON OIL FILTER, R/S 15-50 | 1 | FRN28201 | < |
| 56 | FILTER HEAD OIL (RS15-50) | 1 | FRN28100 | < |
| 57 | NIPPLE-BLACK 3/4 X 2 1/2" | 1 | FPTN0510AS | < |
| 58 | CONNECTOR 3/4"NPT X 3/4 OD ELBOW 90 DEGREE | 1 | FRN60084 | < |
| 59 | HHCS M16 X 90MM" ZINC PLATED | 4 | 2102019850 | < |
| 60 | NUT HEX M16 x 2.0 | 2 | FVH1531 | < |
| 61 | VALVE RELIEF 1/2" 200 PSIG | 1 | FRN42817 | < |
| 62 | ELBOW-1/2" STREET-BLACK | 1 | FPTS04AG | < |
| 63 | HHCS 3/8-16 X 1" GRADE 5 ZINC PLATED | 4 | FVH12KH1 | < |
| 64 | LOCKWASHER 3/8" ZINC PLATED | 4 | FVH35K1 | < |
| 65 | WASHER FLAT 3/8" ZINC PLATED | 4 | FVH32K1 | < |
| 66 | CAP-OIL FILLER/SIGHT GLASS | 1 | FCS741 | < |
| 67 | COMBINATION OIL FILL AND SIGHT GLASS | 1 | FCS740 | < |
| 68 | ADAPTOR STR ELBW 1 1/16-12 UN X 3/4"NPTF | 1 | FRN60078 | < |
| 69 | BUSHING 3/4 X 1/2 | 1 | FPTB0504AG | < |
| 70 | BALL VALVE,1/2",20KG/CM2 | 1 | 2104010213 | < |
| 71 | PLUG- SQUARE HEAD-STEEL 1/2" | 1 | FPTP04AG | < |
| 72 | CONNECTOR ELBOW, 3/4 OD X 1 1/16 - 12UN | 2 | FRN52141 | < |
| 73 | BUSHING REDUCING 1" X 3/4" GALV STEEL | 1 | FPTB0605AG | < |
| 74 | ADAPTOR 3/4"NPT X 1 1/16-12UN MALE | 1 | FRN52139 | < |
| 75 | O-RING SAE12 VITON | 1 | FRN52139-1 | < |
| 76 | VALVE THERMO SAE12 170 DEG F | 1 | FRN42403 | < |
| 77 | CONNECTOR 1 1/16"-12UN X 3/4" OD. STRAIGHT, VITON O-RING | 1 | FRN52143 | < |
| 78 | LOCKWASHER LIGHT 1/2" ZINC PLATED | 12 | FVH35P1 | < |
| 79 | HHCS 1/2-13UNC X 2 3/4 “GRADE 5 | 4 | FVH12PS1 | < |
| 80 | SCREW,1/4-20 X 0.5 HHCS GR 5 | 4 | FVH12FF1 | < |
| 81 | HHCS M16-2.0 X 30MM ZN PL | 4 | FVH1471 | < |
| 82 | ORIFICE 7.6MM OD | 1 | FRN52191 | < |
| 83 | LOCKWASHER SPLIT 5/8" | 8 | FVH35R1 | < |
| 84 | FLANGE DISCHARGE SAE24 BSA31S ELBOW | 1 | FRN10728 | < |
| 84A | O-RFING#231 VITON FOR FRN10728 | 1 | FRN10728-1 | < |
| 85 | CONNECTOR 1 1/2"OD X 1 7/8-12 UN STRGHT, VITON O-RING | 1 | FVAB707 | < |
| 86 | LOCK WASHER 16MM | 8 | FVH1234 | < |
| 87 | SCREW HEX M16 X 2.0 X 90MM CL8.8 Zn PL | 4 | FVH1485 | < |
| 88 | TEMP SWITCH 1/2"NPT 1” PROBE | 2 | FRN18658 | < |
| 89 | ADAPTER 1/4"BSPP X 1/4"NPT | 1 | FVAA769-1 | < |
| 90 | O-RING FOR FVAA769-1 | 1 | FVA769-2 | < |
| 91 | CLAMP 3 1/8 - 6 | 2 | FRN24076-5A | < |
| 92 | BELT | 1 | ||
| 93 | BUSHING, AIR END | 1 | ||
| 94 | SHEAVE, AIR END | 1 | SEE TABLE 1 | |
| 95 | BUSHING MOTOR | 1 | ||
| 96 | SHEAVE, MOTOR | 1 | ||
| 98 | HHCS 1/2-13UNC X 1 GRADE 5 ZINC PLATED | 8 | FVH12PH1 | < |
| 99 | FRG AIR CLEANER R/S40-50 | 1 | FRN24077 | < |
| 99A | AIR PRIMARY | 1 | FRN24077-1 | < |
| 99B | AIR SAFETY | 1 | FRN24077-2 | < |
| 100 | MOUNT PLATE, HDF | 1 | FRN24079-11 | < |
| 101 | ROD THREADED M16 X 2.0 | 1 | FVL2402 | < |
| 102 | PLATE MNT, HDF, RS20-50 W/EYE BOLT MOTORS | 1 | FRN24076-9 | < |
| 103 | ELBOW REDUCING 3.5" X 3" | 1 | FRN24077-3 | < |
| 104 | TUBE STEEL 1/4" OD X.030 WALL | 1 | FOFE1030 | < |
| 105 | TEE-REDUCING 1 1/4"NPT X 1/2"NPT X 1 1/4"NPT | 1 | FVAE804 | < |
| 106 | NIPPLE, 1/4"NPT X 1 1/2" SHORT | 2 | FPTN0208AG | < |
| 107 | TEE 1/4"NPT PIPE GALV | 2 | FPTT02AG | < |
| 108 | CONNECTOR 1 1/2"OD.X1 7/8"- 12UN ELBOW | 1 | FRN52145 | < |
| 109 | NIPPLE 1 1/4"NPT X 2 1/2"LONG | 1 | FPTN0710AS | < |
| 110 | CONNECTOR 1 1/4NPT X 1 1/4OD COMPRESSION | 1 | FVA788 | < |
| 111 | TUBE STEEL 1/4" OD X.030 WALL SEPARATOR TO SIGHT GLASS | 1 | FOFE963 | < |
| 112 | HHCS 5/8-11UNC X 1 1/2 GRADE 5 | 8 | FVH12RH1 | < |
| 113 | SLEEVE 1/4 OD | 2 | FVAA757 | < |
| 114 | NYLON TUBE 3/8" BLACK | - | FVA1626 | < |
| 115 | NUT 1/4" OD STEEL | 2 | FVAA756 | < |
| 116 | HOSE ASSEMBLY 5/8ID X 41.75"LG WITH SAE 37 FEMALE SWIVEL | 1 | FRN60717 | < |
| 117 | UNION | 1 | FVAA701 | < |
| 118 | CONNECTOR SCAVENGER COMPR. | 1 | FRN52151 | < |
| 119 | COOLER SUPPORT-RIGHT | 1 | FCS701 | < |
| 120 | MTG BRACKET 8" DI | 1 | FRN24077-4 | < |
| 121 | SWITCH-PRESSURE W/O BLEEDER 1/4"NPT | 1 | F1240007 | < |
| 122 | NIPPLE 1/4 X CLOSE, 304SS | 1 | FPTN0200AG | < |
| 123 | 1/4"X1/2" BULKHEAD FITTING | 1 | FRN10616 | < |
| 124 | CONNECTOR, 1/4OD X 1/4NPT, MALE, STR. | 1 | FRN52150-5 | < |
| 125 | O-RING #246 | 1 | FRN10713-1 | < |
| 126 | VALVE INJECTION | 1 | FRN24589 | < |
| 127 | ADAPTER 3/8 BSPPM X 3/8 NPTF | 1 | FVA770 | < |
| 128 | CONNECTOR, 3/8 OD X 3/8NPT | 1 | FRN52150-10 | < |
| 129 | INSERT 3/8 TUBE | 2 | FRN52150-12 | < |
| PARTS LIST FOR MAJOR PARTS GROUP | ||||
| ITEM NO. | DESCRIPTION | QTY. | RSB40 W/C | RSB50 W/C |
| 1 | BASE | 1 | FRN10176 | < |
| 2 | SEPARATOR, OIL/AIR | 1 | FRN10222-2 | < |
| 4 | MOUNTING PLATE, AIR END | 1 | FRN10127 | < |
| 6 | PANEL, CONTROL | 1 | ||
| SIZE, “K” | F1330000 | < | ||
| SIZE, “N” | F1330001 | < | ||
| 7 | COOLER, OIL, W/C | 1 | FRN33157 | < |
| 8 | AFTERCOOLER, W/C | 1 | FCX740 | < |
| 9 | COOLER SUPPORT ASSEMBLY, L.H. | 1 | FCS700 | < |
| 10 | COOLER SUPPORT ASSEMBLY, R.H. | 1 | FCS701 | < |
| 11 | SUPPORT, CONTROL PANEL | 2 | FCS667-2 | < |
| 15 | BOLT M16 | 2 | FVH1471 | < |
| 16 | BOLT, M12 | 4 | FVH1485 | < |
| 17 | LOCKWASHER, M12 | 4 | FVH1240 | < |
| 23 | SCREW, HEX WASHER HEAD, ¼-20 x ¾” LG. | 13 | FVH12FF1 | < |
| 24 | LOCKWASHER, 1/4" | 17 | FVH35F1 | < |
| 25 | WASHER, FLAT, 1/4" | 4 | FVH32F1 | < |
| 26 | SCREW, HEX HEAD CAP, 5/16-18 x 1" LG. | 14 | FVH12HH1 | < |
| 27 | LOCKWASHER, 5/16" | 14 | FVH35H1 | < |
| 28 | WASHER, FLAT, 5/16" | 14 | FVH32H1 | < |
| 29 | BOLT 5/8-11 X 1” | 4 | FVH12RH1 | < |
| 31 | LOCKWASHER 5/8” | 4 | FVH35R1 | < |
| 32 | LOCKWASHER, 1/2" | 8 | FVH35P1 | < |
| 33 | WASHER, FLAT, 1/2" | 8 | FVH32P1 | < |
| 34 | AIR END SEAL KIT (NOT SHOWN) | 1 | FRN90437-1 | < |
| 36 | AFTERCOOLER BRACKET | 1 | FRN10171A | < |
| 37 | AFTERCOOLER BRACKET | 1 | FRN10171B | < |
| 38 | BOLT 1/2-13 X 2 3/4” LG | 4 | FVH12PH1 | < |
At H&K, we service and maintain the following compressor brands. Piston and Rotary screw compressors:
Curtis compressors
Ingersoll Rand compressors
Quincy compressors
Champion compressors
Atlas Copco compressors
Kellogg compressors
(call: 214-428-2868)
www.hkaircompressors.com
| TABLE 1: SHEAVES, BUSHING AND BELTS | ||||||
| ITEM | R/S 40 | R/S 50 | ||||
| PSI | DESCRIPTION | |||||
| N | QTY | PART NO. | QTY | PART NO. | ||
| 97 | SHEAVE, MOTOR | 1 | FRN14106 | 1 | FRN14134 | |
| 96 | BUSHING, MOTOR | 1 | FVDC215 | 1 | FRN14177-5 | |
| 100 | 95 | SHEAVE, AIR END | 1 | FRN14106 | 1 | FRN14137 |
| 94 | BUSHING, AIR END | 1 | FRN14177-11 | 1 | FRN14177-11 | |
| 93 | BELT | 4 | FRN14315-1 | 5 | FRN14315-1 | |
| 97 | SHEAVE, MOTOR | 1 | FRN14109 | 1 | FRN14134 | |
| 96 | BUSHING, MOTOR | 1 | FVDC215 | 1 | FRN14177-5 | |
| 125 | 95 | SHEAVE, AIR END | 1 | FRN14110 | 1 | FRN14135 |
| 94 | BUSHING, AIR END | 1 | FRN14177-11 | 1 | FRN14177-11 | |
| 93 | BELT | 4 | FRN14316-1 | 6 | FRN14316-1 | |
| 97 | SHEAVE, MOTOR | 1 | FRN14106 | 1 | FRN14134 | |
| 96 | BUSHING, MOTOR | 1 | FVDC215 | 1 | FRN14177-5 | |
| 150 | 95 | SHEAVE, AIR END | 1 | FRN14110 | 1 | FRN14134 |
| 94 | BUSHING, AIR END | 1 | FRN14177-11 | 1 | FRN14177-11 | |
| 93 | BELT | 4 | FRN14316-1 | 5 | FRN14316-1 | |
| 97 | SHEAVE, MOTOR | 1 | FRN14106 | 1 | FRN14135 | |
| 96 | BUSHING, MOTOR | 1 | FVDC215 | 1 | FRN14177-5 | |
| 175 | 95 | SHEAVE, AIR END | 1 | FRN14186 | 1 | FRN14134 |
| 94 | BUSHING, AIR END | 1 | FRN14177-11 | 1 | FRN14177-11 | |
| 93 | BELT | 4 | FRN14316-1 | 5 | FRN14316-1 |
214-428-2868
Curtis rotary screw parts
Curtis rotary screw service
| PARTS LIST FOR AIR AND OIL PIPING GROUP | ||||
| ITEM | DESCRIPTION | QTY. | RSB40 | RSB50 |
| NO. | W/C | W/C | ||
| 1 | AIR END | 1 | 2A05190279 | < |
| 2 | FLANGE, DISCHARGE | 1 | FRN10728 | < |
| 3 | "O" RING #231 | 1 | FRN10728-1 | < |
| 4 | SCREW HEX M16 X 2.0 X 90MM CL8.8 Zn PL | 4 | FVH1485 | < |
| 5 | LOCK WASHER, 16mm | 4 | FVH1234 | < |
| 6 | ADAPTER 1/4"BSPP X 1/4"NPT | 1 | FVAA769-1 | < |
| 7 | BOLT M16-1.75 X 90MM | 4 | 2102019850 | < |
| 8 | COMPRESSION CONNECTOR 1/4"NPTx 3/8”OD ELBOW | 1 | FRN52150-12 | < |
| 9 | O-RING FOR FVAA769-1 | 1 | FVA769-2 | < |
| 11 | VALVE, INLET DN65 | 1 | 2104050162 | < |
| 11A | O-RING FOR | 1 | INCLUDED | < |
| 13 | ELBOW,1 1/4”NPT STREET | 1 | FVAA722 | < |
| 15 | CONNECTOR, STRAIGHT | 1 | FVAB707 | < |
| 16 | TUBE, STEEL | 1 | FOFE981 | < |
| 17 | CONNECTOR, ELBOW | 1 | FRN52145 | < |
| 18 | CONNECTOR 3/4BSPP X 3/4" 37FL | 1 | FVAC749 | < |
| 19 | HOSE, ASSEMBLY | 1 | FRN60713 | < |
| 20 | CONNECTOR, 3/4” OD FL x 3/4" NPT, ELBOW | 1 | FRN60084 | < |
| 21 | OIL FILTER HEAD | 1 | FRN28100 | < |
| 22 | ELEMENT, OIL FILTER | 1 | FRN28201 | < |
| 23 | TEE - 3/4" NPT GALV. | 1 | FVAE803 | < |
| 24 | NIPPLE, 1/4" NPT, CLOSE | 1 | FPTN0200AG | < |
| 25 | CONNECTOR, ELBOW, 3/4" OD x 3/4"NPT | 1 | FRN60084 | < |
| 26 | TUBE, BY-PASS TO OIL FILTER | 1 | FOFE960 | < |
| 27 | CONNECTOR, STRAIGHT, 3/4"OD x SAE12 | 1 | FRN52143 | < |
| 28 | ADAPTOR, MALE - 3/4" NPT x SAE12 | 1 | FRN52139 | < |
| 28A | O-RING FOR RN52139 | 1 | FRN52139-1 | < |
| 29 | THERMOWELL 1/4"BSPPx 7/16-24UNS 6MM PRO | 1 | FRN18694 | < |
| 29A | SEAL BONDED BSPP 1/4 | 1 | 2109120008 | |
| 30 | ELEMENT, SEPARATOR | 1 | FRN27518 | < |
| 32 | TEE - 1/4" | 4 | FPTT02AG | < |
| 33 | CONNECTOR, 1/4” ID X 1/4” NPT MALE, ELBOW | 2 | FRN52150-2 | < |
| 34 | TEE, RUN - 1/4” NPT X 1/4” OD TUBE X 1/4” OD TUBE | 2 | FVA745 | < |
| 35 | TUBE, NYLON, BLACK, #11, 1/4" O.D. | - | FVA1626 | < |
| 36 | COMBINATION OIL FILL AND SIGHT GLASS | 1 | FRN52171 | < |
| 37 | CAP W/ VENT HOLE | 1 | FCS741 | < |
| 39 | VALVE, MINIMUM PRESSURE | 1 | FRN42126-4 | < |
| 40 | KIT, SERVICE, MINIMUM PRESSURE VALVE | 1 | FRN42126-1 | < |
| 41 | CONNECTOR, 1 l/4"OD FL x 1 1/4"NPT STR | 2 | FVAA722 | < |
| 42 | HOSE, 0.375"IDX41.75" | 1 | FRN60717 | < |
| 43 | TEE, 1 1/4"NPT | 1 | FVAE804 | < |
| 44 | CONNECTOR, ELBOW, 3/4"OD x SAE12 | 2 | FRN52I41 | < |
| 45 | TUBE, SEPARATOR TANK TO BY-PASS | 1 | FOFE995 | < |
| 46 | VALVE, THERMO BY-PASS, 170° F | 1 | FRN42403 | < |
| 46A | KIT, SERVICE, THERMO BY-PASS VALVE, 170° F | 1 | FRN42403-1 | < |
| 47 | ADAPTOR STR ELBW 1 1/16-12 UN X 3/4’NPTF | 1 | FRN60078 | < |
| 48 | BUSHING 3/4”NPT X 1/2”NPT | 1 | FPTB0504AG | < |
| 49 | VALVE, BALL-1/2” | 1 | 2104010213 | < |
| 50 | PLUG 1/2” NPT. | 1 | FPTP04AG | < |
| ITEM | DESCRIPTION | QTY. | RSB40 | RSB50 |
| NO. | W/C | W/C | ||
| 51 | SWITCH, TEMPERATURE 1/2”NPT | 1 | FRN18658 | < |
| 52 | SWITCH, TEMPERATURE 1/4”NPT | 1 | FRN18659 | < |
| 53 | ELBOW, STREET 1/2”NPT | 1 | FPTS04AG | < |
| 54 | AIR GAUGE, 2 1/2” DIA., 1/4”NPT LIQUID FILLED | 1 | FRN30323 | < |
| 54A | AIR GAUGE, 2 1/2” DIA., 1/4”NPT LIQUID FILLED | 1 | FRN30322 | < |
| 56 | COMPRESSION CONNECTOR, 1/4” NPT X 1/4”,SCAV.LINE | 1 | FRN52151 | < |
| 57 | STEEL TUBE, 1/4” OD | 1 | FOFE963 | < |
| 58 | STEEL TUBE, 1/4” OD | 1 | FOFE968 | < |
| 59 | NUT, 1/4” OD, STEEL | 2 | FVAA756 | < |
| 60 | SLEEVE, 1/4” OD, STEEL | 2 | FVAA757 | < |
| 61 | SIGHT GLASS | 1 | FRN52174 | < |
| 62 | ORIFICE SCAVENGER COMPRESSION CONNECTOR | 1 | FRN52131-3 | < |
| 63 | CHECK VALVE IN-LINE 1/4” | 1 | FVV834 | < |
| 64 | ELBOW 1/4 NPTM X 1/4” NPTM | 1 | FVAA754 | < |
| 65 | ADAPTER 1/8 BSPP MALE X 1/4 NTF | 3 | FVAA745 | < |
| 66 | BOND SEAL VITON USE W/VAA745 ADAP | 3 | FVAA746 | < |
| 67 | VALVE, RELIEF - 1/2” 200 PSI | 1 | FRN42817 | < |
| 68 | BUSHING, 1 ” NPT X 3/4” NPT | 3 | FPTB0605AG | < |
| 69 | BUSHING, 2” NPT X 1 1/4” NPT | 2 | FPTB0907AG | < |
| 71 | BUSHING, 3/4” NPT X 1/2” NPT | 4 | FPTB0504AG | < |
| 72 | NIPPLE, 1/2”” NPT, CLOSE. | 4 | FPTN0200AG | < |
| 73 | ELBOW, 1/2” NPT | 4 | FPTS04AG | < |
| 75 | CONNECTOR, 1/2” (WATER HOSE) | 2 | FVE676 | < |
| 76 | HOSE, 1/2” OD, MULTI-PURPOSE | 3’ | FRN60070 | < |
| 77 | CLAMP, WORM DRIVE HOSE | 2 | FRN60072 | < |
| 78 | NIPPLE,1 1/4”NPT X 2 1/2”LG | 1 | FPTN0716AS | < |
| 79 | WATER MODULATING VALVE, 1/2” | 1 | FCF1552 | < |
| 80 | WELL, WATER VALVE, 3/4” X 4 1/2” | 1 | FCF1559 | < |
| 81 | UNION, 1/2” NPT | 1 | FVAC883 | < |
| 83 | BULCKHEAD FITTING 1/2”(FOR ENCLOSED UNIT ONLY) | 1 | FRN10617-1 | < |
| 84 | HOSE 1/2” OD, MULTI PURPOSE( FOR ENCLOSED UNIT ONLY) | 5’ | FRN60070 | < |
| 85 | CLAMP, WORM DRIVE HOSE( FOR ENCLOSED UNIT ONLY) | 2 | FRN60072 | < |
| 86 | CONNECTOR, 1/2” (WATER HOSE)( FOR ENCLOSED UNIT ONLY) | 2 | FRN60071 | < |
| 88 | BALL VALVE 3/8” NPT | 1 | 2104010213 | < |
| 89 | PLUG 1/4”NPT | 1 | F1479239 | < |
| 90 | SEPARAOR TANK CROSS (NOT SHOWN) | 1 | FRN10140 | < |
| 92 | HD AIR FILTER | 1 | FRN24077 | < |
| 92A | FILTER ELEMENT PRIMARY | 1 | FRN24077-1 | < |
| 92B | FILTER ELEMENT SAFETY | 1 | FRN24077-2 | < |
| 93 | CLAMP 3 1/8-16 | 2 | FRN24076-5A | < |
| 94 | ELBOW 3.5 | 1 | FRN24077-5 | < |
| 95 | MOUNTING BRACKET 8”DIA | 1 | FRN24077-4 | < |
| 96 | MOUNTING PLATE MOTOR | 1 | FRN24076-9 | < |
| 97 | THREAD ROD M16 | 0.5’ | FVL2402 | < |
| 98 | MOUNTING PLATE HDF | 1 | FRN24079-11 | < |
| 99 | NUT HEX M16 | 2 | FVH1531 | < |
| 100 | HHCS 5/16-18 X 1" GRADE 5 | 2 | FVH12HH1 | < |
| 101 | FLAT WASHER 5/16” | 4 | FVH32H1 | < |
| 102 | LOCK WASHER 5/16” | 2 | FVH35H1 | < |
| 103 | NUT HEX 5/16-18 ZINC PLATED | 2 | FVH15H1 | < |
| ITEM NO. | DESCRIPTION | QTY. | RSB40 | RSB50 |
| 1 | CONTROL BACK PANEL | |||
| 2 | STARTER WITH INTERCHANGEABLE HEATERS | SEE TABLE 2 | ||
| 3 | STARTER SIZE “A” WITH INTERCHANGABLE HEATERS | 1 | FRN18959 | < |
| 4 | FUSE BLOCK - 30A, 600V | 1 | FRN18314-1 | < |
| 5 | TERMINAL BLOCK | 6 | F1330042 | < |
| 6 | TERMINAL BLOCK END STOP | 1 | F1330043 | < |
| 7 | TRANSFOMER, 150VA,FUSED, 200/208/230/460-120V | |||
| 8 | FUSE, TRANSFORMER, PRIMARY | SEE TABLE 2 | ||
| 9 | FUSE, TRANSFORMER, SECONDARY | |||
| 10 | RELAY, 4 POLE, 120V, DPDT | 1 | F1330062 | < |
| 11 | SOCKET | 1 | F1330049 | < |
| 12 | TIMER, 60 MIN., PLUG-IN | 1 | F1330026 | < |
| 13 | PUSH BUTTON START SWITCH | 1 | FRN18116-M22 | < |
| 14 | PUSH BUTTON STOP SWITCH (RED) | 1 | FRN18118-M22 | < |
| 15 | 2 POSITION SELECTOR SWITCH (CONST/AUTO) | 1 | FRN18104-9M22 | < |
| 16 | 2 POSITION SELECTOR SWITCH (LOAD/UNLOAD) | 1 | FRN18104-7M22 | < |
| 17 | HOURMETER | 1 | F1330048 | < |
| 18 | AMBER LIGHT (STAND BY) | 1 | FRN18218-M22 | < |
| 19 | RED LIGHT (STOP) | 1 | FRN18217-M22 | < |
| 20 | GREEN LIGHT (POWER ON) | 1 | FRN18219-M22 | < |
| 21 | TEMPERATURE GAUGE | 1 | FRN18692 | < |
| 22 | HEATER - MAIN (NOT SHOWN) | |||
| 23 | HEATER - FAN (NOT SHOWN) | SEE TABLE 2 | ||
| 24 | FUSE, FAN (NOT SHOWN) | |||
| 25 | AUX CONTACTOR | 1 | FVSB886 | < |
| 26 | CONTACTOR NO/NC (Y-DELTA ONLY) | 1 | N/A | < |
| 27 | ANTI-START PRESSURE SWITCH | 1 | FRN18134 | < |
| 28 | LUG, GROUNDING | 2 | FVE779 | < |
| 29 | ENCLOSURE | 1 | F1330058 | < |
| ITEM | DESCRIPTION | QTY. | RSB40-50 |
| NO. | |||
| 1 | CONTROL PANEL ASSEMBLY | ||
| 2 | STARTER WITH INTERCHANGEABLE HEATERS (MAIN MOTOR) | SEE TABLE 3 | |
| 3 | STARTER WITH INTERCHANGABLE HEATERS (FAN) | ||
| 4 | FUSE BLOCK - 30A, 600V | 1 | FRN18314-1 |
| 5 | TERMINAL BLOCK | 26 | F1330042 |
| 6 | END STOP | 2 | F1330043 |
| 7 | TRANSFORMER | ||
| 8 | FUSE, TRANSFORMER, PRIMARY | SEE TABLE 2 | |
| 9 | FUSE, TRANSFORMER, SECONDARY | ||
| 10 | RELAY, 4 POLE, 120V, DPDT | 2 | F1330062 |
| 11 | SOCKET | 2 | F1330049 |
| 12 | TIMER, 60 MIN., PLUG-IN | 1 | F1330026 |
| 13 | TIMER, 30 SEC., PLUG-IN | 1 | F1330031 |
| 14 | ENCLOSURE | 1 | FRN18059 |
| 15 | PUSH BUTTON START SWITCH (GREEN) | 1 | FRN18116-M22 |
| 16 | PUSH BUTTON STOP SWITCH (RED) | 1 | FRN18118-M22 |
| 17 | 2 POSITION SELECTOR SWITCH (CONST/AUTO) | 1 | FRN18104-9M22 |
| 18 | 2 POSITION SELECTOR SWITCH (LOAD/UNLOAD) | 1 | FRN18104-7M22 |
| 19 | HOURMETER | 1 | F1330048 |
| 20 | AMBER LIGHT (STAND BY) | 1 | FRN18218-M22 |
| 21 | RED LIGHT (STOP) | 1 | FRN18217-M22 |
| 22 | GREEN LIGHT (POWER ON) | 1 | FRN18219-M22 |
| 23 | TEMPERATURE GAUGE | 1 | FRN18683 |
| 24 | HEATER - MAIN (NOT SHOWN) | ||
| 25 | HEATER - FAN (NOT SHOWN) | SEE TABLE 3 | |
| 26 | FUSE, FAN (NOT SHOWN) | ||
| 27 | VALVE, SOLENOID | 1 | FRN18422 |
| 28 | SWITCH, PRESSURE | 1 | FRN18133-2 |
| 29 | SWITCH, ANTI-START PRESSURE | 1 | FRN18134 |
| 30 | LUG, GROUNDING | 2 | FVE779 |
| 31 | CONTACTOR REV. M1-S/M1-S WITH NO/NC | SEE TABLE 3 | |
| 32 | NIPPLE 1/4”NPT X CLOSE | 1 | FVA13BAV |
| WIRING DIAGRAM FOR Y-DELTA | FCAB1665A |
| ITEM | DESCRIPTION | QTY. | 200 VOLT | 230 VOLT | 460 VOLT | 575 VOLT | |
| NO. | |||||||
| 1 | CONTROL PANEL | 1 | F1330001 | F1330001 | F1330000 | F1330078 | |
| 2 | SIZE “K” STARTER | 1 | N/A | N/A | FRN18960 | < | |
| 2 | SIZE “N” STARTER | 1 | FRN18963 | < | N/A | N/A | |
| 2 | SIZE “S” STARTER | 1 | N/A | N/A | N/A | N/A | |
| 3 | SIZE “A” STARTER (FAN) AIR COOLED ONLY | 1 | FRN18959 | < | < | < | |
| 3 | SIZE “B” STARTER (FAN) AIR COOLED ONLY | 1 | N/A | N/A | N/A | N/A | |
| 7 | TRANSFORMER, 150VA,FUSED, 120V | 1 | F1330075 | < | < | F1330055 | |
| 7 | TRANSFORMER, 250VA,FUSED, 120V | 1 | N/A | N/A | N/A | N/A | |
| RSB | 8 | FUSE, TRANSFORMER, PRIMARY | 2 | FRN18345-1 | < | < | < |
| 40 | 9 | FUSE, TRANSFORMER, SECONDARY | 1 | FRN18351 | < | < | < |
| 24 | HEATER - MAIN (NOT SHOWN) | 1 | FRN18990 | FRN18989 | FRN18982 | FRN18981 | |
| 25 | HEATER - FAN (NOT SHOWN) AIR COOLED ONLY | 1 | FRN18975 | FRN18974 | FRN18972 | FRN18971 | |
| 26 | FUSE, FAN (NOT SHOWN) AIR COOLED ONLY | 3 | FRN18317-1 | FRN18317 | FRN18316-1 | FVE396 | |
| 1 | CONTROL PANEL | 1 | F1330061 | F1330001 | F1330000 | F1330078 | |
| 2 | SIZE “K” STARTER | 1 | N/A | N/A | FRN18960 | < | |
| 2 | SIZE “N” STARTER | 1 | N/A | FRN18963 | N/A | N/A | |
| 2 | SIZE “S” STARTER | 1 | FRN18860 | N/A | N/A | N/A | |
| 3 | SIZE “A” STARTER(FAN) AIR COOLED ONLY | 1 | N/A | FRN18959 | < | < | |
| RSB | 3 | SIZE “B” STARTER(FAN) AIR COOLED ONLY | 1 | FRN18950 | N/A | N/A | N/A |
| 7 | TRANSFORMER, 150VA,FUSED, 120V | 1 | N/A | F1330075 | < | < | |
| 50 | 7 | TRANSFORMER, 250VA,FUSED, 120V | 1 | F1330076 | N/A | N/A | N/A |
| 8 | FUSE, TRANSFORMER, PRIMARY | 2 | FVE385 | FRN18345-1 | < | < | |
| 9 | FUSE, TRANSFORMER, SECONDARY | 1 | FRN18354 | FRN18351 | < | < | |
| 24 | HEATER - MAIN (NOT SHOWN) | 1 | FRN18972 | FRN18990 | FRN18983 | FRN18982 | |
| 25 | HEATER - FAN (NOT SHOWN) AIR COOLED ONLY | 1 | FRN18976 | FRN18975 | FRN18973 | FRN18972 | |
| 26 | FUSE, FAN(NOT SHOWN) AIR COOLED ONLY | 3 | FVE399 | FRN18317-1 | FRN18316-2 | FRN08316-1 |
| ITEM | 200 | 230 | 460 | 575 | |||
| DESCRIPTION | QTY | ||||||
| NO | VOLT | VOLT | VOLT | VOLT | |||
| 1 | CONTROL PANEL ASSEMBLY | 1 | F1330089 | F1330088 | F1330088 | F1330088 | |
| 2 | SIZE “N” STARTER | 1 | RN18963 | N/A | N/A | N/A | |
| SIZE “K” STARTER | 1 | N/A | FRN18960 | FRN18960 | FRN18960 | ||
| 31 | CONTACTOR REV. M1-S/M1-S WITH | 1 | FRN18540 | N/A | N/A | N/A | |
| NO/NC, SIZE “N” | |||||||
| SIZE “K” | 1 | N/A | FRN18536 | FRN18536 | FRN18536 | ||
| RSB | 3 | SIZE “E” STARTER (FAN) | 1 | FRN18965 | FRN18965 | FRN18965 | FRN18965 |
| 40-50 | |||||||
| 7 | TRANSFORMER, 250VA, FUSED, 120V | 1 | F1330076 | F1330054 | F1330054 | F1330054 | |
| 8 | FUSE, TRANSFORMER, PRIMARY | 2 | FVE334 | FVE334 | FVE334 | FVE334 | |
| 9 | FUSE, TRANSFORMER, SECONDARY | 1 | FRN18393 | FRN18393 | FRN18393 | FRN18393 | |
| 24 | HEATER - MAIN | 1 | FRN18988 | FRN18983 | FRN18981 | FRN18980 | |
| 25 | HEATER - FAN | 1 | FRN18975 | FRN18975 | FRN18973 | FRN18972 | |
| 26 | FUSE, FAN | 3 | FVE399 | FVE399 | FRN18316-3 | FRN18316-2 |
www.hkaircompressors.com
| PART LIST FOR THE RSB40-50 TANK MOUNTED | ||||
| ITEM | PART NUMBER | |||
| Q | ||||
| NO | RSB 40 | RSB 50 | ||
| 1 | SCREW,5/16-18 X 3/4" GRADE 5 | 1 | FVH12HH1 | < |
| 2 | LOCKWASHER-KANTLINK-SPLIT | 1 | FVH35H | < |
| 3 | WASHER-FLAT-CUT 5/16" | 1 | FVH32H | < |
| 4 | MOUNTS-VIBRATION | 1 | FRN60255 | < |
| 6 | NIPPLE 1/4 X CLOSE | 1 | FPTN0200AG | < |
| 7 | VALVE-BALL 1/2" | 1 | 2104010213 | < |
| 8 | ELBOW, 1/4" X 1/4", 90 DEGREE MALE (LONG) | 2 | FRN52150-2 | < |
| 9 | BUSHING, 2"NPT X 1 1/4"NPT GALV | 1 | FPTB0907AG | < |
| 10 | ASME TANK 200 GAL GRASS | 1 | FOFD247A | < |
| 11 | BUSHING 1" X 3/4" | 1 | FPTB0605AG | < |
| 12 | PLUG-SQUARE HEAD-STEEL 1/4" | 1 | F1479239 | < |
| 13 | PLUG-SQUARE HEAD-CORED 1 1/4" | 1 | F1030004 | < |
| 14 | PLUG- SQUARE HEAD-STEEL 1/2" | 2 | FPTP04AG | < |
| 15 | BUSHING 3/4 X 1/2" | 1 | FPTB0504AG | < |
| 16 | NIPPLE-CLOSE 1/2" | 1 | FPTN0400AG | < |
| 19 | ELBOW-STREET 1/4" | 1 | FVAA754 | < |
| 21 | GAUGE,AIR 2"DIAL,1/4"NPT BACK MOUNT CONN., 0-300 PSI | 2 | FRN30323 | < |
| 22 | ELBOW-90 DEGREE 1/4" | 1 | FVAA754 | < |
| 23 | TEE 1/4" 150# M.I. | 1 | FPTT02AG | < |
| 24 | CONNECTOR 1 1/4" NPT X 1 1/4" OD. | 1 | FVAA722 | < |
| 25 | TUBING-NYLON | 1 | FVA1626 | < |
| 26 | HOSE ASSY | 1 | FRN60144 | < |
| 27 | DRAIN COCK 1/4" | 1 | FVV514 | < |
| 20 | ||||
| CAP297-1 | ||||
| ITEM | PART NUMBER | |||
| Q | ||||
| NO | RSB 40 | RSB 50 | ||
| 1 | BALL VALVE-3/8", 200# PRESSURE | 1 | FVV539 | < |
| 2 | TEE-BLACK 3/8" | 1 | FPTT03AB | < |
| 3 | NIPPLE-GALV. 3/8 X 6" | 1 | FPTN0317AG | < |
| 4 | UNION-GROUND JOINT-GALV. 3/8" | 1 | FVAC806 | < |
| 5 | NIPPLE-GALV. 3/8 X 3" | 2 | FPTN0311AG | < |
| 6 | BUSHING 3/8 X 1/4, GALV | 2 | FPTB0302AG | < |
| 7 | NIPPLE-GALV.-CLOSE 3/8" | 1 | FPTN0311AG | < |
| 8 | DRAIN COCK 1/4" | 1 | FVV514 | < |
| 9 | LOCK WASHER ZINC PLATED 1/4" MEDIUM | 4 | FVH35F1 | < |
| 10 | NUT-FINISHED-HEX 1/4-20 ZINC PLATED | 2 | FVH15F1 | < |
| 11 | WASHER FLAT CUT 1/4" | 4 | FVH32F1 | < |
| 12 | HHCS 1/4-20 X 3/4" LONG ZINC PLATED | 2 | FVH12FF1 | < |
| 13 | BRACE-AUTO. DRAIN PIPING | 1 | FOFE950 | < |
| 14 | DRAIN, AUTO-TIMER,1/60/115V 300PSI 7/16" ORIFICE, 3/8" | 1 | FVA536-1 | < |
| 15 | U BOLT #401 | 1 | FVH2202 | < |
| 16 | BUSHING-GALV. 1/2 X 3/8" | 1 | FPTB0403AG | < |
| ITEM | Q | PART NUMBER | ||
| NO | RSB 40 | RSB 50 | ||
| 1 | CONDENSATE AUTOMATIC DRAIN #508 3/8"NPT 175 PSIG | 1 | FVAA511 | < |
| 2 | BALL VALVE-3/8", 200# PRESSURE | 1 | FVV539 | < |
| 3 | TEE 3/8 PIPE GLV | 1 | FVA10CF | < |
| 4 | UNION-GROUND JOINT-GALV. 3/8" | 1 | FVAC806 | < |
| 5 | NIPPLE-GALV.-CLOSE 3/8" | 1 | FPTN0300AG | < |
| 6 | NIPPLE-GALV. 3/8 X 6" | 1 | FPTN0317AG | < |
| 7 | NIPPLE-GALV. 3/8 X 3" | 2 | FPTN0311AG | < |
| 8 | DRAIN COCK 1/4" | 1 | FVV514 | < |
| 9 | HHCS 1/4-20 X 3/4" LONG ZINC PLATED | 2 | FVH12FF1 | < |
| 10 | NUT-FINISHED-HEX 1/4-20 ZINC PLATED | 2 | FVH15F1 | < |
| 11 | LOCK WASHER ZINC PLATED 1/4" MEDIUM | 4 | FVH35F1 | < |
| 12 | WASHER FLAT CUT 1/4" | 4 | FVH32F1 | < |
| 13 | BUSHING 3/8 X 1/4", GALV | 2 | FPTB0302AG | < |
| 14 | BRACE-AUTO. DRAIN PIPING | 1 | FOFE950 | < |
| 15 | U BOLT #401 | 1 | FVH2202 | < |
| 16 | BUSHING-GALV. 1/2 X 3/8" | 1 | FPTB0403AG | < |
| 17 | TUBING-NYLON | 1 | FVA1601 | < |
| DESCRIPTION | QTY | RSB 40-50 |
| FRONT PANEL | 1 | FRN10042-1F |
| FRONT PANEL - FOR C-H CONTROL PANEL 37.5" X 21.5" | 1 | FRN10042D-1F |
| LEFT SIDE PANEL | 1 | FRN10042-2F |
| RIGHT SIDE PANEL | 1 | FRN10042-3F |
| BACK PANEL | 1 | FRN10042-4F |
| TOP PANEL | 2 | FRN10042-5F |
| TOP CROSS SUPPORT | 1 | FRN10042-6DG |
| SCREW, SOCKET HEAD CAP, BUTTON HEAD, 1/4-20 x 1 | ||
| 8 | FVH1737 | |
| 1/2” LG . | ||
| SCREW 1/4-20 X 7/8”LG. | 8 | FVH12FG1 |
| LOCKWASHER, 1/4” | 8 | FVH35F1 |
| WASHER, FLAT, 1/4” | 8 | FVH32F1 |
| GAUGE, AIR PRESSURE, 2 1/2”, LIQUID FILLED | 2 | FRN30322 |
| CONNECTOR | ||
| 2 | FRN52150-7 | |
| STRAIGHT | ||
| TEE RUN 1/4”OD X 1/4”OD X 1/4”NPT | 2 | FVA745 |
| TUBING 1/4"OD, BLACK NYLON | - | FVA1626 |
| LATCH | 4 | FCS914 |
| LOCKWASHER, INTERNAL TOOTH, 1/4” | 12 | FVH38F |
| PIN | 8 | FRN10020-1F |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | "O" RING #231 |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | 1/4"X1/2" BULKHEAD FITTING |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | 2 POSITION SELECTOR SWITCH (CONST/AUTO) |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | 2 POSITION SELECTOR SWITCH (LOAD/UNLOAD) |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | ADAPTER 1/4"BSPP X 1/4"NPT |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | ADAPTER 1/8 BSPP MALE X 1/4 NPTF |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | ADAPTER 1/8 BSPP MALE X 1/4 NTF |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | ADAPTER 3/8 BSPPM X 3/8 NPTF |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | ADAPTOR 3/4"NPT X 1 1/16-12UN MALE |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | ADAPTOR STR ELBW 1 1/16-12 UN X 3/4"NPTF |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | ADAPTOR STR ELBW 1 1/16-12 UN X 3/4’NPTF |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | ADAPTOR, MALE - 3/4" NPT x SAE12 |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | AIR END |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | AIR GAUGE, 2 1/2” DIA., 1/4”NPT LIQUID FILLED |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | AIR PRIMARY |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | AIR SAFETY |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | AMBER LIGHT (STAND BY) |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | ANTI-START PRESSURE SWITCH |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | AUX CONTACTOR |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | BALL VALVE 3/8” NPT |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | BALL VALVE,1/2",20KG/CM2 |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | BASE 42 X 72 DARK GREY RS40-50F, 50D |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | BELT |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | BELTGUARD, BACK BSA32 R/S40-50F |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | BOLT M16-1.75 X 90MM |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | BOND SEAL VITON USE W/VAA745 ADAP |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | BRACKET, OIL FILTER |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | BSA31S(4v5/CURTIS/SingleSeal/RAL7026) |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | BULCKHEAD FITTING 1/2”(FOR ENCLOSED UNIT ONLY) |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | BUSHING 3/4 X 1/2 |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | BUSHING 3/4”NPT X 1/2”NPT |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | BUSHING MOTOR |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | BUSHING REDUCING 1" X 3/4" GALV STEEL |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | BUSHING, 1 ” NPT X 3/4” NPT |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | BUSHING, 2” NPT X 1 1/4” NPT |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | BUSHING, 3/4” NPT X 1/2” NPT |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | BUSHING, AIR END |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | CAP W/ VENT HOLE |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | CAP-OIL FILLER/SIGHT GLASS |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | CHECK VALVE IN-LINE 1/4” |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | CHECK/SIGHT GLASS/2mm ORIFICE COMBO VALVE |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | CLAMP 3 1/8 - 6 |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | CLAMP 3 1/8-16 |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | CLAMP, WORM DRIVE HOSE |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | CLAMP, WORM DRIVE HOSE( FOR ENCLOSED UNIT ONLY) |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | COMBINATION OIL FILL AND SIGHT GLASS |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | COMPRESSION CONNECTOR 1/4"NPTx 3/8”OD ELBOW |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | COMPRESSION CONNECTOR, 1/4” NPT X 1/4”,SCAV.LINE |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | CONNECTOR 1 1/16"-12UN X 3/4" OD. STRAIGHT, VITON O-RING |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | CONNECTOR 1 1/2"OD X 1 7/8-12 UN STRGHT, VITON O-RING |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | CONNECTOR 1 1/2"OD.X1 7/8"- 12UN ELBOW |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | CONNECTOR 1 1/4"NPT X 1 1/4"OD ELBOW-MALE |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | CONNECTOR 1 1/4NPT X 1 1/4OD COMPRESSION |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | CONNECTOR 3/4"NPT X 3/4 OD ELBOW 90 DEGREE |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | CONNECTOR 3/4"NPT X 3/4"OD.STRAIGHT |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | CONNECTOR 3/4BSPP X 3/4" 37FL |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | CONNECTOR ELBOW, 3/4 OD X 1 1/16 - 12UN |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | CONNECTOR SCAVENGER COMPR. |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | CONNECTOR, 1 l/4"OD FL x 1 1/4"NPT STR |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | CONNECTOR, 1/2” (WATER HOSE) |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | CONNECTOR, 1/2” (WATER HOSE)( FOR ENCLOSED UNIT ONLY) |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | CONNECTOR, 1/4” ID X 1/4” NPT MALE, ELBOW |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | CONNECTOR, 1/4OD X 1/4NPT, MALE, ELBOW |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | CONNECTOR, 1/4OD X 1/4NPT, MALE, STR. |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | CONNECTOR, 3/4” OD FL x 3/4" NPT, ELBOW |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | CONNECTOR, 3/8 OD X 3/8NPT |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | CONNECTOR, ELBOW |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | CONNECTOR, ELBOW, 3/4" OD x 3/4"NPT |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | CONNECTOR, ELBOW, 3/4"OD x SAE12 |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | CONNECTOR, STRAIGHT |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | CONNECTOR, STRAIGHT, 3/4"OD x SAE12 |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | CONTACTOR NO/NC (Y-DELTA ONLY) |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | CONTACTOR REV. M1-S/M1-S WITH NO/NC |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | CONTROL BACK PANEL |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | CONTROL PANEL ASSEMBLY |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | CONTROL PANEL SIZE "K" |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | CONTROL PANEL SIZE "N" |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | COOLER AIR/OIL (R/S 40-50) |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | COOLER SUPPORT-LEFT |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | COOLER SUPPORT-RIGHT |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | DESCRIPTION |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | DRAIN COCK 1/4" |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | ELBOW 1/4 NPTM X 1/4” NPTM |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | ELBOW 3.5 |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | ELBOW REDUCING 3.5" X 3" |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | ELBOW, 1/2” NPT |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | ELBOW, MALE 90 DEGREE 1/4" NPTM X 1/4" NPTM STEEL |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | ELBOW, STREET 1/2”NPT |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | ELBOW,1 1/4”NPT STREET |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | ELBOW-1/2" STREET-BLACK |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | ELEMENT, OIL FILTER |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | ELEMENT, SEPARATOR |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | ENCLOSURE |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | END STOP |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | FAN MOTOR MOUNT R/S 40-50 |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | FAN SHROUD |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | FAN-ASSY 45 DEG PITCH |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | FILTER ELEMENT PRIMARY |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | FILTER ELEMENT SAFETY |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | FILTER HEAD OIL (RS15-50) |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | FLANGE DISCHARGE SAE24 BSA31S ELBOW |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | FLANGE, DISCHARGE |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | FLAT WASHER 5/16 ZINC PLATED |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | FLAT WASHER 5/16” |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | FRG AIR CLEANER R/S40-50 |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | FUSE BLOCK - 30A, 600V |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | FUSE, FAN (NOT SHOWN) |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | FUSE, TRANSFORMER, PRIMARY |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | FUSE, TRANSFORMER, SECONDARY |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | GREEN LIGHT (POWER ON) |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | GUARD BELT FRONT R/S 40-50 |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | GUARD CLIPS |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | GUARD FAN 24 " RD WIRE |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | HD AIR FILTER |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | HEATER - FAN (NOT SHOWN) |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | HEATER - MAIN (NOT SHOWN) |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | HHCS 1/2-13UNC X 1 GRADE 5 ZINC PLATED |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | HHCS 1/2-13UNC X 2 3/4 “GRADE 5 |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | HHCS 1/4-20 X 3/4" LONG ZINC PLATED |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | HHCS 3/8-16 X 1" GRADE 5 ZINC PLATED |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | HHCS 5/16-18 X 1" GRADE 5 |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | HHCS 5/16-18 X 1" GRADE 5 ZINC PLATED |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | HHCS 5/8-11UNC X 1 1/2 GRADE 5 |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | HHCS M16 X 90MM" ZINC PLATED |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | HHCS M16-2.0 X 30MM ZN PL |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | HOSE 1/2” OD, MULTI PURPOSE( FOR ENCLOSED UNIT ONLY) |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | HOSE ASSEMBLY 5/8ID X 41.75"LG WITH SAE 37 FEMALE SWIVEL |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | HOSE, 0.375"IDX41.75" |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | HOSE, 1/2” OD, MULTI-PURPOSE |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | HOSE, ASSEMBLY |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | HOURMETER |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | INLET VALVE DN65 110V |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | INSERT 3/8 TUBE |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | KIT REPAIR MIN. PRESSURE VALVE |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | KIT, SERVICE, MINIMUM PRESSURE VALVE |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | KIT, SERVICE, THERMO BY-PASS VALVE, 170° F |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | LOCK WASHER 16MM |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | LOCK WASHER 5/16 SPLIT ZINC PLATED |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | LOCK WASHER 5/16” |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | LOCK WASHER ZINC PLATED 1/4" MEDIUM |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | LOCK WASHER, 16mm |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | LOCKWASHER 3/8" ZINC PLATED |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | LOCKWASHER LIGHT 1/2" ZINC PLATED |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | LOCKWASHER SPLIT 5/8" |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | LUG, GROUNDING |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | MOTOR 1 1/2HP, 3 PHASE, 60HZ, 200V ODP |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | MOTOR 1 1/2HP, 3 PHASE, 60HZ, 230/460V ODP |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | MOTOR 1 1/2HP, 3 PHASE, 60HZ, 575V ODP |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | MOTOR BASE ODP |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | MOTOR, 3PHASE, 60 HZ, 230/460V ODP |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | MOTOR, 3PHASE, 60HZ, 200V, ODP |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | MOTOR, 3PHASE, 60HZ, 575V, ODP |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | MOUNT BASE BSA31S BOLTED RSB40-50 |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | MOUNT PLATE, HDF |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | MOUNTING BRACKET 8”DIA |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | MOUNTING PLATE HDF |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | MOUNTING PLATE MOTOR |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | MTG BRACKET 8" DI |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | NIPPLE 1 1/4 X 5 1/2 |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | NIPPLE 1 1/4"NPT X 2 1/2"LONG |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | NIPPLE 1 X 5 1/2" |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | NIPPLE 1/4 X CLOSE, 304SS |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | NIPPLE 1/4”NPT X CLOSE |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | NIPPLE, 1/2”” NPT, CLOSE. |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | NIPPLE, 1/4" NPT, CLOSE |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | NIPPLE, 1/4"NPT X 1 1/2" SHORT |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | NIPPLE,1 1/4”NPT X 2 1/2”LG |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | NIPPLE-BLACK 3/4 X 2 1/2" |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | NUT 1/4" OD STEEL |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | NUT HEX 5/16-18 ZINC PLATED |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | NUT HEX M16 |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | NUT HEX M16 x 2.0 |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | NUT, 1/4” OD, STEEL |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | NUT-HEX 10-24 |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | NYLON TUBE 3/8" BLACK |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | OIL FILTER HEAD |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | O-RFING#231 VITON FOR FRN10728 |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | ORIFICE 7.6MM OD |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | ORIFICE SCAVENGER COMPRESSION CONNECTOR |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | O-RING |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | O-RING #246 |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | O-RING FOR |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | O-RING FOR FVAA769-1 |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | O-RING FOR RN52139 |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | O-RING SAE12 VITON |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | PARTS LIST FOR AIR AND OIL PIPING GROUP |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | PLATE MNT, HDF, RS20-50 W/EYE BOLT MOTORS |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | PLUG 1/2” NPT. |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | PLUG 1/4”NPT |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | PLUG PLASTIC, 2" SQ. TUBE |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | PLUG- SQUARE HEAD-STEEL 1/2" |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | PRESSURE-AIR GAUGE, 300 PSI 2 1/2 " |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | PUSH BUTTON START SWITCH |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | PUSH BUTTON START SWITCH (GREEN) |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | PUSH BUTTON STOP SWITCH (RED) |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | RED LIGHT (STOP) |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | RELAY, 4 POLE, 120V, DPDT |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | ROD THREADED M16 X 2.0 |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | SCREW HEX M16 X 2.0 X 90MM CL8.8 Zn PL |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | SCREW,1/4-20 X 0.5 HHCS GR 5 |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | SCREW-HEX HD. MACHINE 10-24 |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | SEAL BONDED BSPP 1/4 |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | SEAL BONDED W/VAA745 ADAP |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | SEPARAOR TANK CROSS (NOT SHOWN) |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | SEPARATOR, ELEMENT |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | SHEAVE, AIR END |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | SHEAVE, MOTOR |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | SIGHT GLASS |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | SLEEVE 1/4 OD |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | SLEEVE, 1/4” OD, STEEL |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | SOCKET |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | SPIN ON OIL FILTER, R/S 15-50 |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | STARTER SIZE “A” WITH INTERCHANGABLE HEATERS |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | STARTER WITH INTERCHANGABLE HEATERS (FAN) |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | STARTER WITH INTERCHANGEABLE HEATERS |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | STARTER WITH INTERCHANGEABLE HEATERS (MAIN MOTOR) |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | STEEL TUBE, 1/4” OD |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | SUPPORT, ELECTRICAL ENCL. 39" |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | SWITCH, ANTI-START PRESSURE |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | SWITCH, PRESSURE |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | SWITCH, TEMPERATURE 1/2”NPT |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | SWITCH, TEMPERATURE 1/4”NPT |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | SWITCH-PRESSURE W/O BLEEDER 1/4"NPT |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | TANK AIR/OIL SEPARATOR 14" DIA 19 GAL |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | TEE - 1/4" |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | TEE - 3/4" NPT GALV. |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | TEE 1/4"NPT PIPE GALV |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | TEE REDUCING 1 X 3/4 X 3/4 |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | TEE, 1 1/4"NPT |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | TEE, RUN - 1/4” NPT X 1/4” OD TUBE X 1/4” OD TUBE |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | TEE-REDUCING 1 1/4"NPT X 1/2"NPT X 1 1/4"NPT |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | TEMP SWITCH 1/2"NPT 1” PROBE |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | TEMPERATURE GAUGE |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | TERMINAL BLOCK |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | TERMINAL BLOCK END STOP |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | THERMOWELL 1/4"BSPPx 7/16-24UNS 6MM PRO |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | THREAD ROD M16 |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | TIMER, 30 SEC., PLUG-IN |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | TIMER, 60 MIN., PLUG-IN |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | TRANSFOMER, 150VA,FUSED, 200/208/230/460-120V |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | TRANSFORMER |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | TUBE 1 1/2" O.D. |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | TUBE 1 1/4" O.D.X 0.049 |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | TUBE STEEL 1/4" OD X.030 WALL |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | TUBE STEEL 1/4" OD X.030 WALL SEPARATOR TO SIGHT GLASS |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | TUBE, BY-PASS TO OIL FILTER |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | TUBE, NYLON, BLACK, #11, 1/4" O.D. |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | TUBE, SEPARATOR TANK TO BY-PASS |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | TUBE, STEEL |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | TUBE-BY-PASS TO OIL FILTER 3/4" OD. |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | TUBE-SEPARATOR TANK TO BY-PASS 3/4"OD |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | UNION |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | UNION, 1/2” NPT |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | VALVE INJECTION |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | VALVE MIN PRESS 1 1/4" |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | VALVE RELIEF 1/2" 200 PSIG |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | VALVE THERMO SAE12 170 DEG F |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | VALVE, BALL-1/2” |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | VALVE, INLET DN65 |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | VALVE, MINIMUM PRESSURE |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | VALVE, RELIEF - 1/2” 200 PSI |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | VALVE, SOLENOID |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | VALVE, THERMO BY-PASS, 170° F |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | WASHER FLAT 3/8" ZINC PLATED |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | WASHER-CUT-FLAT 1/4" |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | WATER MODULATING VALVE, 1/2” |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | WELL, WATER VALVE, 3/4” X 4 1/2” |
| CURTIS | RS SERIES | ROTARY SCREW COMPRESSOR | WIRING DIAGRAM FOR Y-DELTA |
214-428-2868
Curtis rotary screw parts
Curtis rotary screw service
www.hkaircompressors.com
No comments:
Post a Comment
